| Supported Display Resolution |
|
| Computer formats |
640 x 480, 60, 72, 75 Hz, 720 x 400, 70 Hz, 800 x 600, 60, 75 Hz, 1024 x 768, 60, 75 Hz, 1280 x 768, 60 Hz, 1280 x 800, 60 Hz, 1280 x 960, 60 Hz, 1280 x 1024, 60 Hz, 1360 x 768, 60 Hz, 1366 x 768, 60 Hz, 1600 x 1200, 60 Hz, 1920 x 1080, 60 Hz
|
| Video formats |
720p, 50, 60 Hz, 1080i, 25, 30 Hz, 1080p, 50, 60 Hz |
|
|
| Connectivity |
|
| Video input |
DVI-I (x 1), DisplayPort 1.2 (x 1), HDMI 2.0 (x 2) |
| Video output |
DisplayPort 1.2 (x 1), HDMI 2.0 (x 1) |
| Audio input |
3.5 mm jack |
| Audio output |
3.5 mm jack |
| External control |
RJ45 |
|
RS232C (in/out) 2.5 mm jack |
|
IR (in/out) 3.5 mm jack |
| Other connections |
USB 2.0 (x 2), OPS |
|
|
| Convenience |
|
| Placement |
Landscape (24/7) |
|
Portrait (24/7) |
| Screen-saving functions |
Pixel Shift, Low Brightness |
| Signal loop through |
DisplayPort, RS232, HDMI, IR Loop through |
| Ease of installation |
Carrying Handles |
|
Smart Insert |
| Energy-saving functions |
Smart Power |
| Network controllable |
RS232, RJ45 |
| Keyboard control |
Hidden, Lockable |
| Remote control signal |
Lockable |
|
|
| Dimensions |
|
| Smart Insert mount |
100 mm x 100 mm pitch, 6 x M4L6 |
| Set Width |
1248.6 |
| Set Height |
719.4 |
| Set Depth |
85 |
| Set Width (inch) |
49.16 |
| Set Height (inch) |
28.32 |
| Set Depth (inch) |
3.35 |
| Bezel width |
17.5 mm (even bezel) |
| Wall Mount |
400 x 400 mm, M6 |
| Smart insert height |
100 |
| Product weight |
30.37 |
| Product weight (lb) |
66.95 |
|
|
| Operating conditions |
|
| Temperature range (operation) |
0 ~ 40 |
| Temperature range (storage) |
-20 ~ 60 |
| MTBF |
50.000 |
| Humidity range (operation)[RH] |
20~80% RH (No condensation) |
| Humidity range (storage) [RH] |
5~95% RH (No condensation) |
| Altitude |
0 ~ 3000 m |
|
|
| Power |
|
| Consumption (Typical) |
245 |
| Consumption (Max) |
430 W |
| Standby power consumption |
<0.5 W |
| Mains power |
100 ~ 240 VAC, 50 ~ 60 Hz |
|
|
| Sound |
|
| Built-in speakers |
2 x 10 W RMS |
|
|
| Multimedia Applications |
|
| USB Playback Video |
AVI, MP4, MPEG, MPG, TS, VOB, MPEG4 |
| USB Playback Picture |
BMP, JPEG, PNG, JPG |
|
|
| Accessories |
|
| Included Accessories |
IR sensor cable (1.8 m) (x 1), Philips logo (x 1), AC Power Cord, AC Switch Cover, Quick start guide, Remote control and AAA batteries, USB cover and screw x 1, Wire Clamper (x 3), Edge Alignment Kit, Open-frame kit |
|
|
| Miscellaneous |
|
| Warranty |
3 year warranty |
| On-Screen Display Languages |
English, French, German, Italian, Polish, Turkish, Russian, Simplified Chinese, Spanish, Traditional Chinese, Arabic, Japanese, Dutch, Portuguese |
| Regulatory approvals |
CE, CB, FCC, Class A, UL/cUL |
outline-drawing-philips-55bdl4002h-v01-20220831
