LG 49VL5PJ Full HD Slim Bezel Video Wall
Product code:By using this daisy-chained network feature, you can execute commands such as controlling, monitoring and even updating firmware.
Description
Panel
| Screen Size | 49" |
|---|---|
| Panel Technology | IPS |
| Aspect Ratio | 16 : 9 |
| Native Resolution | 1,920 x 1,080 (FHD) |
| Refresh Rate | 60Hz |
| Brightness | 500 |
| Contrast Ratio | 1,000:1 |
| Dynamic CR | 500,000 : 1 |
| Color gamut | NTSC 72% |
| Viewing Angle (H x V) | 178x178 |
| Color Depth | 10bit, 1.07Billion colors |
| Response Time | 8 ms (G to G) |
| Surface Treatment (Haze) | 3% |
| Life Time (Typ.) | 60,000Hrs |
| Life Time (Min.) | 50,000Hrs |
| Operation Hours (Hours / Days) | 24/7 |
| Portrait / Landscape | Yes / Yes |
| OS | webOS 4.1 |
Additional information
Mechanical Specification
| Bezel Color | Black |
|---|---|
| Bezel Width | T/R/L/B : 2.25/1.25/2.25/1.25mm |
| Weight (Head) | 17.8 Kg |
| Packed Weight | 21.9 Kg |
| Monitor Dimensions (W × H × D) | 1,077.6 x 607.8 x 89.7 mm |
| Carton Dimensions (W × H × D) | 1,198 x 247 x 756 mm (Box outer size) |
| Handle | Yes |
| VESA™ Standard Mount Interface | 600 x 400 |
Special Feature
| IP Rating | IP5X tested |
|---|
Key Feature
| HW | Internal Memory (8 GB), Temperature Sensor, BLU Sensor, Acceleration(Gyro) Sensor |
|---|---|
| SW | webOS 4.1, Embedded CMS (Local Contents Scheduling, Group Manager), USB Plug & Play, Fail Over, Background Image (No Signal Image), Sync Mode (RS-232C Sync, Local Network Sync), Video Tag (4), Play via URL, Rotation (Screen Rotation, External Input Rotation), Gapless Playback, Tile Mode Setting (Max. 15 × 15), Setting Data Cloning, SNMP, ISM Method, Auto Set ID, Status Mailing, Control Manager, 3rd Party Compatibility (Crestron Connected®2)), Power (Smart Energy Saving, PM Mode, Wake on LAN, Network Ready), HDMI-CEC3), SI Server Setting, webRTC, Pro:Idiom, W/B Setting by Grey Scale, Scan Inversion |
Connectivity
| Input | HDMI 2 (HDCP 2.2), DP (HDCP 2.2), DVI-D (HDCP 1.4), Audio In, RS-232C In, RJ45 (LAN), IR In, USB 2.0 Type A |
|---|---|
| Output | DP Out (Input : HDMI / DVI / DP), Audio Out, RS-232C Out |
Environment Conditions
| Operation Temperature | 0 °C to 40 °C |
|---|---|
| Operation Humidity | 10 % to 80 % |
Power
| Power Supply | AC 100-240V~, 50/60Hz |
|---|---|
| Power Type | Built-In Power |
Power Consumption
| Typ. | 110 W |
|---|---|
| Max. | 120 W |
| Smart Energy Saving | 70 W |
| DPM | 0.5 W |
| Power off | 0.5 W |
| BTU (British Thermal Unit) | 375 BTU/Hr(Typ.), 409 BTU/Hr(Max) |
Certification
| Safety | CB / NRTL |
|---|---|
| EMC | FCC Class “A” / CE / KC |
| ErP | Yes (EU Only) |
Software Compatibility
| SuperSign CMS, SuperSign Control / Control+, SuperSign WB, SuperSign WB, SuperSign Media Editor, LG ConnectedCare |
Accessory
| Basic | Remote Controller(include battery 2ea), Power Cord, RS232C cable, Lan calbe, DP cable, IR Receiver, Guide Bracket, Screws, Manual |
|---|
