LG 55SVH7PF-H Full HD 0.44mm Even Bezel Video Wall

Product code: 55SVH7PF-H

The 0.44mm Even Bezel Video Wall using LG's leading display technology, creates a truly seamless view with vivid color throughout the assembled large screen. Also, designed with an external power box, it is more optimal for Mission Critical Environment, where continuous, stable and reliable power supply is required for 24 hours.

SEND AN ENQUIRY

Description

Panel

Screen Size55"
Panel TechnologyIPS
Aspect Ratio16:9
Native Resolution1,920 x 1,080 (FHD)
Brightness(Typ.,cd/m²)  700
Contrast Ratio1,100:1
Viewing Angle (H x V)178 x 178
Response Time8 ms (G to G)
Surface TreatmentHaze 28%
Life Time (Typ.)60,000 Hrs
Operation Hours24 Hrs
OrientationLandscape & Portrait

Additional information

Connectivity

Input  HDMI (2), DP, DVI-D, Audio, USB, Power In, Power Loop In
Output  DP, Audio, Power Loop Out
External Control  RS232C In/out, RJ45 (LAN) In/out, IR In


Mechanical Specifications

Bezel Color  Black
Bezel Width  0.44 mm (Even)
Monitor Dimensions (W × H × D)  1,210.51 x 681.22 x 86.5 mm
Weight (Head)  16.8 kg
Handle  Yes
VESA™ Standard Mount Interface  600 x 400 mm


Environment Conditions

Operation Temperature  0°C to 40°C
Operation Humidity  10 % to 80 %


Power Consumption

Typ.  188W
Max.  240W


Certification

Safety  CB / NRTL
EMC  FCC Class “A” / CE / KC


Software Compatibility

Content Management Software  SuperSign CMS
Control and Monitoring Software  SuperSign Control / Control+
Signage365Care  Yes


Accessory

Basic  Remote Controller, RS232C Cable, Lan Cable, DP Cable, IR Receiver, Guide Bracket, Screws, Manual, Power loop cable
Optional  Wall Mount (Landscape : WM-L640V, Portrait : WM-P640V), External Power Box (LPLG001-FV3)), Power cable (6m, ACC-LAPPC06), Power cable (60m, ACC-LAPPC60), OPS Kit (KT-OPSF)
