Philips X-Line 55BDL8107X/00 Videowall
Product code:Take presentations and corporate branding to the next level. The Philips X-Line Videowall display brings your content to life to ensure absolute audience engagement in every setting with Pure Colour Pro.
SEND AN ENQUIRYDescription
Picture/Display
| Contrast ratio (typical) | 1200:1 |
|---|---|
| Viewing angle (vertical) | 178 degree |
| Display colours | 16.7 M |
| Viewing angle (horizontal) | 178 degree |
| Panel resolution | 1920 x 1080p |
| Pixel pitch | 0.63 x 0.63 mm |
| Response time (typical) | 8 ms |
| Aspect ratio | 16:9 |
| Dynamic contrast ratio | 500,000:1 |
| Brightness | 700 cd/m² |
| Diagonal screen size (inch) | 54.5 inch |
| Haze | 25% |
| Optimum resolution | 1920 x 1080 @ 60 Hz |
| Diagonal screen size (metric) | 138.7 cm |
Additional information
Supported Display Resolution
| Computer formats | 640 x 480, 60, 72, 75 Hz, 720 x 400, 70 Hz, 800 x 600, 60, 75 Hz, 1024 x 768, 60, 75 Hz, 1280 x 768, 60 Hz, 1280 x 800, 60 Hz, 1280 x 960, 60 Hz, 1280 x 1024, 60 Hz, 1360 x 768, 60 Hz, 1366 x 768, 60 Hz, 1600 x 1200, 60 Hz, 1920 x 1080, 60 Hz, |
|---|---|
| Video formats | 720p, 50, 60 Hz, 1080i, 25, 30 Hz, 1080p, 50, 60 Hz, 2160 P 50, 60 Hz, |
Connectivity
| Video output | Display Port 1.3 |
|---|---|
| External control | IR 3.5 mm jack, LAN RJ45, Signal loopthrough RJ45, |
| Audio input | 3.5 mm mini jack |
| Other connections | OPS, USB 2.0, Thermal sensor, |
| Video input | DVI-D, VGA, Display Port1.3, HDMI 2.0, |
| Audio output | 3.5 mm Mini Jack |
Convenience
| Signal loop through | DisplayPort, RJ45, |
|---|---|
| Energy-saving functions | Smart Power |
| Tiled Matrix | Up to 15 x 15 |
| Network controllable | LAN |
| Ease of installation | Carrying Handles, Smart Insert, |
| Placement | Landscape, Portrait, |
| Screen-saving functions | Pixel Shift, Low Bright |
Dimensions
| Smart Insert mount | 100 mm x 100 mm, 6 x M4 x L6 |
|---|---|
| Set Height (inch) | 26.85 inch |
| Set Width | 1211.1 mm |
| Set Depth | 95.3 mm/94.3 mm mm |
| Product weight | 23.8 kg |
| Set Depth (inch) | 3.75 / 3.71 inch |
| Bezel width | 0.44 mm + 0.44 mm |
| Set Height | 681.9 mm |
| Wall Mount | 400 mm x 400 mm, M6 |
| Set Width (inch) | 47.68 inch |
Operating conditions
| Temperature range (operation) | 0 ~ 40 °C |
|---|---|
| Humidity range (operation)[RH] | 20 - 80% |
| Humidity range (storage) [RH] | 5 - 95% |
| Temperature range (storage) | -20 ~ 60 °C |
| MTBF | 50,000 hour |
| Altitude | 0 ~ 3000 m |
Power
| Standby power consumption | 0.5 W |
|---|---|
| Energy Label Class | G |
| Consumption | EEI lot5 134 W |
Sound
| Built-in speakers | 2 x 10 W |
|---|
Accessories
| Included Accessories | Gap pad x 3, IR sensor cable, Quick start guide, Remote control and AAA batteries, RJ45/RS232 converter, Power cord, DP cable, RJ45 cable, Edge alignment pin, Edge alignment kit, |
|---|---|
| Optional accessories | Edge finishing kit top/bottom: EFK5539, Edge finishing kit left/right: EFK5569, |
Miscellaneous
| Warranty | 3 year warranty |
|---|---|
| Regulatory approvals | CE, FCC, Class A, RoHS, CB, |
| On-Screen Display Languages | Arabic, English, French, German, Italian, Japanese, Polish, Russian, Spanish, Simplified Chinese, Turkish, Traditional Chinese, |
