Philips D-Line 32BDL4511D/00 Digital Signage
Product code:Make it stand out with a fast Philips D-Line Professional FHD display. Philips superb picture quality ensures true colours and intense contrast. You can effortlessly display content from multiple sources on a single screen.
SEND AN ENQUIRYDescription
Picture/Display
| Diagonal screen size (metric) | 81.28 |
|---|---|
| Diagonal screen size (inch) | 32 |
| Panel resolution | 1920 x 1080p |
| Optimum resolution | 1920 x 1080 @ 60 Hz |
| Brightness | 400 |
| Dynamic contrast ratio | 500,000:1 |
| Response time (typical) | 8 |
| Aspect ratio | 16:9 |
| Viewing angle (horizontal) | 178 |
| Viewing angle (vertical) | 178 |
| Pixel pitch | 0.36375 x 0.36375 mm |
| Display colours | 16.7 million |
| Panel technology | ADS |
| Contrast ratio (typical) | 1200:1 |
| Haze | 25% |
Additional information
Supported Display Resolution
| Computer formats | 640 x 480, 60 Hz / 800 x 600, 60 Hz / 1024 x 768, 60 Hz / 1280 x 720, 60 Hz / 1280 x 1024, 60 Hz / 1440 x 900, 60 Hz / 1600 x 900, 60 Hz / 1680 x 1050, 60 Hz / 1920 x 1080, 60 Hz |
|---|---|
| Video formats | 480i, 60 Hz / 480p, 60 Hz / 576p, 50 Hz / 576i, 50 Hz / 720p, 50,60 Hz / 1080i, 50, 60 Hz / 1080p, 50, 60 Hz |
Connectivity
| Video input | Display Port1.2 (x 1), DVI-I (x 1), HDMI 2.0 (x 2), USB 2.0 (x 2) |
|---|---|
| Audio input | 3.5 mm jack |
| Video output | DisplayPort 1.2 (x 1), HDMI 2.0 (x 1) |
| Audio output | 3.5 mm jack |
| External control | IR (in/out) 3.5 mm jack, RJ45, RS232C (in/out) 2.5 mm jack |
Convenience
| Placement | Landscape (24/7), Portrait (24/7) |
|---|---|
| Screen-saving functions | Pixel Shift, Low Bright |
| Signal loop through | DisplayPort, RS232, HDMI, IR Loop through |
| Energy-saving functions | Smart Power |
| Network controllable | RS232/RJ45 |
| Keyboard control | Hidden, Lockable |
Operating conditions
| Temperature range (operation) | 0 ~ 40 |
|---|---|
| Temperature range (storage) | -20 ~ 60 |
| Altitude | 0 ~ 3000 m |
| MTBF | 50,000 |
| Humidity range (operation)[RH] | 20–80% RH (No condensation) |
| Humidity range (storage) [RH] | 5–95% RH (No condensation) |
Power
| Consumption (Typical) | 36 |
|---|---|
| Consumption (Max) | 60 W |
| Standby power consumption | 0.5 W |
| Mains power | 100 ~ 240 VAC, 50 ~ 60 Hz |
| Energy Label Class | G |
Sound
| Built-in speakers | 2 x 10 W RMS |
|---|
Accessories
| Stand | BM05911 (Optional) |
|---|---|
| Included Accessories | Philips logo (x 1), AC power cord, AC Switch Cover, IR sensor cable (1.8 m) (x 1), Quick start guide (x 1), Remote control and AAA batteries, RS232 cable, RS232 daisy-chain cable, USB Cover and screw x 1, Wire Clamper (x 3) |
Miscellaneous
| On-Screen Display Languages | Arabic, Dutch, Danish, English, French, Finnish, German, Italian, Japanese, Norwegian, Polish, Portuguese, Russian, Spanish, Swedish, Simplified Chinese, Turkish, Traditional Chinese |
|---|---|
| Regulatory approvals | CE/FCC Class A/CCC/RoHS/CB/BSMI/EMF/VCCI/PSB/ETL/CECP/EAC |
| Warranty | 3 year warranty |
Multimedia Applications
| USB Playback Video | H.263/H.264/H.265/MPEG |
|---|---|
| USB Playback Picture | BMP/JPEG/PNG |
| USB Playback Audio | AAC/MPEG/HEAAC |
Dimensions
| Set Width | 726.5 |
|---|---|
| Set Height | 425.4 |
| Set Depth | 65.1 (@Wall mount)/ 69.1 (@AC) |
| Set Width (inch) | 28.60 |
| Set Height (inch) | 16.75 |
| Set Depth (inch) | 2.56 inch (@Wall mount) /2.72 (@AC)) |
| Bezel width | 11.9 mm (T/R/L), 17.2 mm (B) |
| Wall Mount | 100 (H) x 100 (V) mm / 200 (H) x 200 (V) mm, M4 |
| Product weight | 5.7 |
| Product weight (lb) | 12.57 |
