| Connectivity |
|
| Audio input |
3.5 mm jack |
| External control |
IR (in/out) 3.5 mm jack |
|
RJ45 |
|
RS232C (in/out) 2.5 mm jack |
|
Ambient Light Sensor |
| Video output |
DisplayPort 1.2 (x 1) |
|
HDMI 2.0 (x 1) |
| Video input |
Display Port1.2 (x 1) |
|
DVI-I (x 1) |
|
HDMI 2.0 (x 3) |
| Other connections |
USB 2.0 (x 2) |
|
OPS |
|
Thermal sensor |
| Audio output |
3.5 mm jack |
|
|
| Convenience |
|
| Network controllable |
RS232 |
|
RJ45 |
| Tiled Matrix |
Up to 15 x 15 |
| Energy-saving functions |
Smart Power |
| Screen-saving functions |
Pixel Shift, Low Bright |
| Placement |
Landscape (24/7) |
|
Portrait (24/7) |
| Signal loop through |
DisplayPort |
|
RS232 |
|
HDMI |
|
IR Loop through |
| Ease of installation |
Carrying Handles |
|
Conformal Coating |
|
|
| Accessories |
|
| Included Accessories |
AC Switch Cover |
|
Philips logo (x 1) |
|
Power cable (x 3) |
|
Quick start guide (x 1) |
|
Remote control and AAA batteries |
|
RS232 cable (3 m) (x 1) |
|
RS232 daisy chain cable (x 1) |
|
USB Cover (x 1) |
| Stand |
BM05922(optional) |
|
|
| Dimensions |
|
| Set Depth (inch) |
3.54 inch (at handle),2.72 (at wall mount) inch |
| Product weight (lb) |
61.3 lb |
| Product weight |
27.8 kg |
| Bezel width |
14.90 mm (Even bezel) |
| Set Depth |
89.90 mm (at handle), 69.0 mm (at wall mount) mm |
| Set Width |
1462.3 mm |
| Set Width (inch) |
57.71 inch |
| Set Height (inch) |
32.96 inch |
| Set Height |
837.3 mm |
| Wall Mount |
400 x 400 mm, M8 |
|
|
| Sound |
|
| Built-in speakers |
2 x 10 W RMS |
|
|
| Power |
|
| Consumption (Max) |
210 W |
| Mains power |
100 ~ 240 VAC, 50 ~ 60 Hz |
| Consumption (Typical) |
128 W |
| Energy Label Class |
G |
| Standby power consumption |
<0.5 W |
|
|
| Multimedia Applications |
|
| USB Playback Picture |
BMP |
|
JPEG |
|
PNG |
| USB Playback Video |
H.264 |
|
H.265 |
|
Motion JPEG |
|
MPEG1/2 |
|
WMV3 |
| USB Playback Audio |
AAC |
|
MPEG |
|
HEAAC |
| Miscellaneous |
|
| Regulatory approvals |
CE |
|
FCC, Class A |
|
CB |
|
BSMI |
|
EAC |
|
EMF |
|
VCCI |
|
PSB |
|
Energy Star 8.0 |
|
ETL |
|
EPA |
| Warranty |
3 year warranty |
| On-Screen Display Languages |
Arabic |
|
Dutch |
|
Danish |
|
English |
|
French |
|
Finnish |
|
German |
|
Italian |
|
Japanese |
|
Norwegian |
|
Polish |
|
Portuguese |
|
Russian |
|
Spanish |
|
Swedish |
|
Simplified Chinese |
|
Turkish |
|
|
| Operating conditions |
|
| Temperature range (storage) |
-20 ~ 60 °C |
| MTBF |
50,000 hour(s) |
| Humidity range (operation)[RH] |
20~80% RH (No condensation) |
| Temperature range (operation) |
0 ~ 40 °C |
| Humidity range (storage) [RH] |
5~95% RH (No condensation) |
| Ingress protection |
IP5X |
| Altitude |
0 ~ 5000 m |
|
|
| Supported Display Resolution |
|
| Computer formats |
640 x 480, 60, 67, 72, 75 Hz |
|
720 x 400, 70 Hz |
|
800 x 600, 56, 60, 72, 75 Hz |
|
1024 x 768, 60, 70, 75 Hz |
|
1152 x 864, 75 Hz |
|
1152 x 870, 75 Hz |
|
1280 x 720, 60 Hz |
|
1280 x 800, 60 Hz |
|
1280 x 1024, 60 Hz |
|
1440 x 900, 60 Hz |
|
1600 x 1200, 60 Hz |
|
1680 x 1050, 60 Hz |
|
1920 x 1080, 60 Hz |
| Video formats |
480p, 60 Hz |
|
576p, 50 Hz |
|
720p, 50, 60 Hz |
|
1080i, 50, 60 Hz |
