| Connectivity |
|
| External control |
RS232C (in/out) 2.5 mm jack |
|
IR (in/out) 3.5 mm jack |
|
RJ45 |
| Audio input |
3.5 mm jack |
| Video input |
USB 2.0 (x 2) |
|
DVI-I (x 1) |
|
HDMI 2.0 (x 2) |
|
USB 3.0 (x1) |
| Other connections |
micro SD |
|
OPS |
| Audio output |
3.5 mm jack |
|
|
| Convenience |
|
| Remote control signal |
Lockable |
| Network controllable |
RS232 |
|
RJ45 |
| Tiled Matrix |
Up to 3 x 3 |
| Energy-saving functions |
Smart Power |
| Placement |
Landscape (24/7) |
|
Portrait (24/7) |
| Signal loop through |
RS232 |
|
IR Loop through |
| Keyboard control |
Hidden |
|
Lockable |
| Ease of installation |
Smart Insert |
|
|
| Accessories |
|
| Included Accessories |
RS232 daisy-chain cable |
|
Philips logo (x 1) |
|
AC Power Cord |
|
AC Switch Cover |
|
Quick start guide |
|
Remote control and AAA batteries |
|
RS232 cable |
|
USB Cover (x 1) |
| Internal Player |
|
| GPU |
G52 MC1 |
| Memory |
16 GB |
|
3 GB DDR |
| CPU |
Quad-Core Cortex A55 |
|
|
| Dimensions |
|
| Bezel width |
14.9 mm (Even bezel) |
| Product weight |
35.75 kg |
| Set Depth (inch) |
2.74(@ wall mount)/ 3.61(@ handle) inch |
| Product weight (lb) |
78.82 lb |
| Set Depth |
69.5 mm (D@wall mount)/91.8 mm (D@handle) mm |
| Set Width |
1683.5 mm |
| Set Width (inch) |
66.28 inch |
| Set Height (inch) |
37.86 inch |
| Wall Mount |
600 mm x 400 mm, M8 |
| Set Height |
961.7 mm |
|
|
| Sound |
|
| Built-in speakers |
2 x 10 W RMS |
|
|
| Power |
|
| Mains power |
100–240 V~, 50/60 Hz |
| Energy Label Class |
D |
| EEI Lot5 power consumption (W) |
80 |
| Power Saving Features |
Smart Power |
| Standby power consumption |
<0.5 W |
|
|
| Multimedia Applications |
|
| USB Playback Video |
MPEG 1/2 (1080p 60 Hz) |
|
MPEG 4 (1080p 60 Hz) |
|
H.263 (1080p 60 Hz) |
|
H.264 (4K2K 60 Hz) |
|
H.265 (4K2K 60 Hz) |
|
VP8 (1080p 60 Hz) |
|
VP9 (4K2K 60 Hz) |
| USB Playback Picture |
JPEG |
|
PNG |
|
BMP |
|
WEBP |
| USB Playback Audio |
AAC |
|
HEAAC |
|
MPEG 1/2/2.5 Layer 3 |
|
MPEG 1/2 Layer 1 |
|
MPEG 1/2 Layer 2 |
| Miscellaneous |
|
| Regulatory approvals |
CE |
|
CB |
|
FCC, Class A |
|
VCCI |
|
RoHS |
|
UL |
| Warranty |
3 year warranty |
| On-Screen Display Languages |
Simplified Chinese |
|
Traditional Chinese |
|
English |
|
French |
|
German |
|
Italian |
|
Polish |
|
Russian |
|
Spanish |
|
Turkish |
|
Japanese |
|
Arabic |
| Operating conditions |
|
| Temperature range (storage) |
-20 ~ 60 °C |
| MTBF |
50,000 hour(s) |
| Temperature range (operation) |
0 ~ 40 °C |
| Humidity range (storage) [RH] |
5~95% RH (No condensation) |
| Humidity range (operation)[RH] |
20~80% RH (No condensation) |
| Altitude |
0 ~ 3000 m |
|
|
| Supported Display Resolution |
|
| Computer formats |
720 x 400, 70 Hz |
|
640 x 480, 60, 67, 75 Hz |
|
800 x 600, 60 Hz |
|
832 x 624, 75 Hz |
|
1024 x 768, 60 Hz |
|
1152 x 870, 75 Hz |
|
1280 x 720, 60 Hz |
|
1920 x 1080, 60 Hz |
|
1680 x 1050, 60 Hz |
|
3840 x 2160, 30, 60 Hz |
| Video formats |
480i, 60 Hz |
|
480p, 60 Hz |
|
576p, 50 Hz |
|
576i, 50 Hz |
|
720p, 50, 60 Hz |
|
1080i, 50, 60 Hz |
|
1080p, 50, 60 Hz |
|
3840 x 2160, 30, 60 Hz |
