Philips T-Line 43BDL3651T/00 Touch Display

Philips T-Line 43BDL3651T/00 Touch Display

Product code: 43BDL3651T/00

Inspire collaboration. Deliver information. This responsive Philips Multi-Touch Professional UHD Display is ideal for multi-finger, multi-user applications, from wayfinding to presentations. Up to 10 touch points can be active at once.

SEND AN ENQUIRY

Description

Picture/Display

Diagonal screen size (metric)	108.0
Diagonal screen size (inch)	43
Panel resolution	3840 x 2160
Optimum resolution	3840 x 2160 @ 60 Hz
Brightness	400
Contrast ratio (typical)	1200:1
Surface treatment	Anti-Glare coating
Aspect ratio	16:9
Response time (typical)	8
Pixel pitch	0.2451 (H) x 0.2451 (V) mm
Display colours	1.07 B
Viewing angle (horizontal)	178
Viewing angle (vertical)	178
Picture enhancement	3/2 - 2/2 motion pull down, 3D Combfilter, Motion compens. deinterlacing, Progressive scan, 3D MA deinterlacing, Dynamic contrast enhancement
Panel technology	IPS
Operating system	Android 8.0

Additional information

Interactivity

Multi-touch technology	Projected capacitive
Touch points	10 simultaneous touch points
Plug and play	HID compliant
Protection glass	3 mm tempered safety glass

Connectivity

Video input	DVI-D (x 1), HDMI 2.0 (x 2), USB 2.0 Type A (x 2), USB 2.0 Type B (x 1), VGA (Analogue D-Sub) (x 1)
Audio input	3.5 mm jack
Audio output	3.5 mm jack
External control	RJ45, IR (in/out) 3.5 mm jack, RS232C (in/out) 2.5 mm jack
Other connections	micro SD, OPS

Supported Display Resolution

Computer formats	640 x 480, 60, 67, 72, 75 Hz / 800 x 600, 56, 60, 72, 75 Hz / 1024 x 768, 60 Hz / 1280 x 768, 60 Hz / 1280 x 800, 60 Hz / 1280 x 1024, 60 Hz / 1360 x 768, 60 Hz / 1366 x 768, 60 Hz / 1440 x 900, 60 Hz / 1600 x 1200, 60 Hz / 1920 x 1080, 60 Hz / 1920 x 1200, 60 Hz / 3840 x 2160, 60 Hz, 50 Hz / 720 x 400, 70 Hz / 800 x 600, 60, 72, 75 Hz
Video formats	480i, 60 Hz / 480p, 60 Hz / 576p, 50 Hz / 576i, 50 Hz / 720p, 50, 60 Hz / 1080i, 50, 60 Hz / 1080p, 50, 60 Hz / 1080i, 25, 30 Hz / 3840 x 2160, 24, 25 Hz / 3840 x 2160, 30Hz / 480i, 30, 60 Hz / 576i, 25, 50 Hz

Convenience

Placement	Landscape (18/7), Portrait (18/7)
Network controllable	RS232/RJ45
Screen-saving functions	Pixel Shift, Low Brightness
Keyboard control	Hidden, Lockable
Remote control signal	Lockable
Energy-saving functions	Smart Power
Signal loop through	IR Loop through, RS232

Dimensions

Set Width	990.0
Set Height	578.2
Set Depth	70.2 (D@Wall mount)/102.7 (D@External OPS box)
Set Width (inch)	38.98
Set Height (inch)	22.76
Set Depth (inch)	2.76 (D@Wall mount)/4.04 (D@External OPS box)
Product weight	17.9
Product weight (lb)	39.46
Bezel width	2.0 mm (T/R/L/B)
Wall Mount	200mm x 200mm, M6

Sound

Built-in speakers	2 x 10 W

Operating conditions

Temperature range (operation)	0 ~ 40
MTBF	50,000
Altitude	0 ~ 3000 m
Temperature range (storage)	-20 ~ 60
Humidity range (operation)[RH]	20–80% (without condensation)
Humidity range (storage) [RH]	5–95% (without condensation)

Power

Mains power	100 ~ 240 VAC, 50/60 Hz
Standby power consumption	<0.5 W
Consumption (Typical)	100
Power Saving Features	Smart Power
Consumption (Max)	220 W
Energy Label Class	G

Accessories

Stand	BM05922 (Optional)
Included Accessories	Cleaning cloth (x 1), IR sensor cable (1.8 m) (x 1), Philips logo (x 1), Power supply cable (3 m), Quick start guide (x 1), Remote control and AAA batteries, RS232 cable (3 m) (x 1), RS232 daisy chain cable (x 1), USB Cover and screw x 1

Miscellaneous

On-Screen Display Languages	Arabic, English, French, German, Italian, Japanese, Polish, Spanish, Turkish, Russian, Simplified Chinese, Traditional Chinese, Danish, Dutch, Finnish, Norwegian, Portuguese, Swedish
Regulatory approvals	CE, CB, BSMI, FCC Class A, CU, ETL, IMDA, PSB, RoHS
Warranty	3 year warranty

Multimedia Applications

USB Playback Audio	AAC/AIF/AIFF/ASF/LPCM/M3U/M4A/MP3/MP4/WAV/WMA
USB Playback Picture	BMP/GIF/JPEG/JPG/PDF
USB Playback Video	M2TS/M4V/MK3D/MKV/MP4/MPEG/MPG/MTS/TS/TTS/VOB/WMV
