Philips T-Line 55BDL3452T/00 Touch Display

Philips T-Line 55BDL3452T/00 Touch Display

Product code: 55BDL3452T/00

Inspire collaboration. Deliver information. This responsive Philips Multi-Touch Professional UHD Display is ideal for multi-finger, multi-user applications—from wayfinding to presentations. Up to 20 touch points can be active at once.

SEND AN ENQUIRY

Description

Picture/Display

Diagonal screen size (metric)	138.8
Diagonal screen size (inch)	55
Panel resolution	3840 x 2160
Optimum resolution	3840 x 2160 @ 60 Hz
Brightness	400
Contrast ratio (typical)	1300:1
Surface treatment	Anti-Glare coating
Aspect ratio	16:9
Response time (typical)	8
Pixel pitch	0.315 (H) x 0.315 (V) mm
Display colours	1.07 B
Viewing angle (horizontal)	178
Viewing angle (vertical)	178
Picture enhancement	3/2 - 2/2 motion pull down, 3D Combfilter, Motion compens. deinterlacing, Progressive scan, 3D MA deinterlacing, Dynamic contrast enhancement
Panel technology	IPS
Operating system	Android 8.0

Additional information

Interactivity

Multi-touch technology	IRHE
Touch points	20 simultaneous touch points
Plug and play	HID compliant
Protection glass	3 mm tempered safety glass

Connectivity

Video input	DVI-D (x 1), HDMI 2.0 (x 2), USB 2.0 Type A (x 2), USB 2.0 Type B (x 1), VGA (Analogue D-Sub) (x 1)
Audio input	3.5 mm jack
Audio output	3.5 mm jack
External control	RJ45, IR (in/out) 3.5 mm jack, RS232C (in/out) 2.5 mm jack
Other connections	micro SD, OPS

Supported Display Resolution

Computer formats	640 x 480, 60, 67, 72, 75 Hz / 800 x 600, 56, 60, 72, 75 Hz / 1024 x 768, 60 Hz / 1280 x 768, 60 Hz / 1280 x 800, 60 Hz / 1280 x 1024, 60 Hz / 1360 x 768, 60 Hz / 1366 x 768, 60 Hz / 1440 x 900, 60 Hz / 1600 x 1200, 60 Hz / 1920 x 1080, 60 Hz / 1920 x 1200, 60 Hz / 720 x 400, 70 Hz / 800 x 600, 60, 72, 75 Hz / 3840 x 2160, 60 Hz, 50 Hz
Video formats	480i, 60 Hz / 480p, 60 Hz / 576p, 50 Hz / 576i, 50 Hz / 720p, 50, 60 Hz / 1080i, 50, 60 Hz / 1080p, 50, 60 Hz / 1080i, 25, 30 Hz / 480i, 30, 60 Hz / 576i, 25, 50 Hz / 3840 x 2160, 24, 25 Hz / 3840 x 2160, 30Hz

Convenience

Placement	Landscape (18/7), Portrait (18/7)
Signal loop through	IR Loop through, RS232
Network controllable	RS232/RJ45
Screen-saving functions	Pixel Shift, Low Brightness
Keyboard control	Hidden, Lockable
Remote control signal	Lockable
Energy-saving functions	Smart Power

Dimensions

Set Width	1272.6
Set Height	743.4
Set Depth	75.5 (D@Wall mount)/81.7 (D@OPS Cover)
Set Width (inch)	50.10
Set Height (inch)	29.27
Set Depth (inch)	2.97 (D@Wall mount)/3.22 (D@OPS Cover)
Product weight	27.0
Product weight (lb)	59.52
Wall Mount	400 x 400 mm, M6
Bezel width	16.3 mm (T/R/L/B)

Sound

Built-in speakers	2 x 10 W

Operating conditions

Temperature range (operation)	0 ~ 40
MTBF	50,000
Altitude	0 ~ 3000 m
Temperature range (storage)	-20~60
Humidity range (operation)[RH]	20–80% (without condensation)
Humidity range (storage) [RH]	5–95% (without condensation)

Power

Mains power	100 ~ 240 VAC, 50/60 Hz
Standby power consumption	<0.5 W
Consumption (Typical)	140
Power Saving Features	Smart Power
Consumption (Max)	270 W
Energy Label Class	G

Accessories

Stand	BM05922 (Optional)
Included Accessories	Cleaning cloth (x 1), IR sensor cable (1.8 m) (x 1), Philips logo (x 1), Power supply cable (3 m), Quick start guide (x 1), Remote control and AAA batteries, RS232 cable (3 m) (x 1), RS232 daisy chain cable (x 1), USB Cover and screw x 1

Miscellaneous

On-Screen Display Languages	Arabic, English, French, German, Italian, Japanese, Polish, Spanish, Turkish, Russian, Simplified Chinese, Traditional Chinese, Danish, Dutch, Finnish, Norwegian, Portuguese, Swedish
Regulatory approvals	BSMI, CB, CE, FCC Class A, RoHS, CU, ETL, IMDA, PSB
Warranty	3 year warranty

Multimedia Applications

USB Playback Picture	BMP/GIF/JPEG/JPG/PDF
USB Playback Audio	AAC/AIF/AIFF/ASF/LPCM/M3U/M4A/MP3/MP4/WAV/WMA
USB Playback Video	M2TS/M4V/MK3D/MKV/MP4/MPEG/MPG/MTS/TS/TTS/VOB/WMV
