| Connectivity |
|
| Video output |
HDMI |
| Audio output |
3.5 mm jack |
| Other connections |
micro SD, USB 2.0 (x 1), USB C |
| External control |
RJ45 |
|
|
| Convenience |
|
| Picture performance |
Advanced colour control |
| Placement |
Landscape (24/7), Portrait (24/7) |
| Screen-saving functions |
Low brightness |
| Programmable side LED |
3 sides |
| Network controllable |
Wi-Fi, BT 5.0, Ethernet |
| Other convenience |
G sensor, NFC, Kensington lock |
| Keyboard control |
Hidden, Lockable |
|
|
| Accessories |
|
| Included Accessories |
AC power adapter, Quick start guide (x 1), USB A to C cable, HDMI cable |
|
|
| Dimensions |
|
| Wall Mount |
75 x 75 mm |
| Set Height |
164 mm |
| Set Width |
262 mm |
| Bezel width (L/R, T/B) |
22 (L/R), 14 (T/B) |
| Set Depth |
24.75 mm |
| Set Width (inch) |
10.32 inch |
| Product weight (lb) |
1.63 lb |
| Product weight |
0.8 kg |
| Set Height (inch) |
6.46 inch |
| Set Depth (inch) |
0.97 inch |
|
|
| Internal Player |
|
| Storage |
16 GB EMMC |
| Memory |
2 GB DDR4 |
| CPU |
RK3568 |
| Wi-Fi |
802.11 ac/a/b/g/n, 2.4/5 GHz |
|
|
| Sound |
|
| Built-in speakers |
2 x 1.5 W |
|
|
| Power |
|
| Consumption (Typical) |
4 W |
| Mains power |
DC12V +/- 5%, 2A, IEEE 802.03at PoE+ |
| Standby power consumption |
<0.5 W |
| Consumption (Max) |
18 W |
|
|
| Operating conditions |
|
| Temperature range (storage) |
-10 ~ 60 °C |
| Altitude |
0 ~ 3000 m |
| Humidity range (operation)[RH] |
30-80% (without condensation) |
| Temperature range (operation) |
0 ~ 40 °C |
| Humidity range (storage) [RH] |
10-85% (without condensation) |
| MTBF |
30,000 hour(s) |
|
|
| Miscellaneous |
|
| On-Screen Display Languages |
Arabic, Dutch, Danish, English, French, Finnish, German, Italian, Japanese, Norwegian, Polish, Portuguese, Russian, Spanish, Swedish, Simplified Chinese, Turkish, Traditional Chinese |
| Regulatory approvals |
CE, FCC, Class A, RoHS, CB, ETL |
| Warranty |
3 year warranty |
|
|
| Interactivity |
|
| Protection glass |
0.7 mm tempered safety glass, Tempered safety glass 7 MOHS |
| Multi-touch technology |
Projected capacitive |
| Touchpoints |
10 simultaneous touch points |
10bdl5051t-2024
