| Connectivity |
|
| Audio output |
3.5 mm Mini Jack (x 1) |
| Video output |
HDMI 2.0 (x 1) |
| Video input |
USB 3.0 (x 3), USB-C (up to 65 W), HDMI 2.0 (x 2) |
| Audio input |
3.5 mm mini jack (x 1), SPDIF (x 1) |
| Other connections |
OPS, USB-B (x 3), micro SD, Micro USB (x 1) (OTG), Thermal sensor |
| External control |
IR (in/out) 3.5 mm jack, RS232C (in/out) 2.5 mm jack, RJ45 x 2 |
|
|
| Convenience |
|
| Ease of installation |
AC Out |
| Remote control signal |
Lockable |
| Screen-saving functions |
Pixel Shift, Low Brightness |
| Placement |
Landscape (18/7) |
| Network controllable |
RS232, RJ45 |
| Other convenience |
Carrying handles |
| Keyboard control |
Lockable |
| Signal loop through |
RS232, IR Loop through |
|
|
| Accessories |
|
| Optional accessories |
Interact dongles |
| Included Accessories |
Cleaning cloth (x 1), HDMI cable, USB-A to B cable (3 m) (x 1), Remote control and AAA batteries, AC Power Cord, Quick start guide, Philips logo (x 1), AC switch cover and Screw x 1, HDMI cable (1.8 m) (x 1), Touch Pen (x 2) |
|
|
| Internal Player |
|
| Storage |
32 GB eMMc |
| GPU |
Multi-Core Mali-G52 |
| CPU |
4 x A73 + 4 x A53 |
| Wi-Fi |
2G/5G/6G 2T2R |
|
|
| Supported Display Resolution |
|
| Video formats |
480i, 60 Hz, 480p, 60 Hz, 1080i, 50, 60 Hz, 1080p, 50, 60 Hz, 2160p, 30, 60 Hz |
| Computer formats |
640 x 350, 70 Hz, 640 x 480, 60, 67, 72, 75 Hz, 640 x 480, 60, 67, 72, 75 Hz, 800 x 600, 56, 60, 72, 75 Hz, 832 x 624, 75 Hz, 848 x 480, 60 Hz, 960 x 720, 75 Hz, 1024 x 768, 60, 70 Hz, 1152 x 864, 60, 70, 75 Hz, 1152 x 900, 66 Hz, 1280 x 720, 60, 70 Hz, 1280 x 768, 60 Hz, 75 Hz, 1280 x 800, 60, 75 Hz, 1280 x 960, 60 Hz, 1280 x 1024, 60, 67, 75 Hz, 1360 x 768, 60 Hz, 1366 x 768, 60 Hz, 1400 x 1050, 60, 75 Hz, 1600 x 900, 60 Hz, 1600 x 1200, 60 Hz, 1680 x 1050, 60 Hz, 1920 x 1080, 60 Hz, 1920 x 1200, 60 Hz, 3840 x 2160, 24, 25, 30, 60 Hz, 1440 x 900, 60 Hz, 720 x 400, 70 Hz |
|
|
| Interactivity |
|
| Protection glass |
Anti-Glare, Blue light filter, Tempered safety glass 7 MOHS |
| Multi-touch technology |
0-gap Infrared touch |
| Plug and play |
HID compliant |
| Touchpoints |
40 simultaneous touch points(depending on application) |
|
|
| Sound |
|
| Built-in speakers |
2 x 20 W |
|
|
| Power |
|
| Energy Label Class |
G |
| Consumption (Typical) |
TBD W |
| Power Saving Features |
Smart Power |
| Consumption (Max) |
TBD |
| Standby power consumption |
<0.5 W |
| Mains power |
100 - 240 V~, 50 - 60 Hz, 7.5 A |
|
|
| Multimedia Applications |
|
| USB Playback Picture |
BMP, JPEG, PNG |
| USB Playback Video |
H.263, H.264, H.265, MPEG1/2, MPEG4, VP8, VP9 |
| USB Playback Audio |
AAC, MPEG, HEAAC |
|
|
| Operating conditions |
|
| Temperature range (storage) |
-20~60 °C |
| Temperature range (operation) |
0 ~ 40 °C |
| Humidity range (storage) [RH] |
5–95% (without condensation) |
| Altitude |
0 ~ 3000 m |
| Humidity range (operation)[RH] |
20–80% (without condensation) |
| MTBF |
50,000 hour(s) |
|
|
| Miscellaneous |
|
| On-Screen Display Languages |
Arabic, Dutch, Danish, English, French, Finnish, German, Italian, Japanese, Norwegian, Polish, Portuguese, Russian, Spanish, Swedish, Simplified Chinese, Turkish, Traditional Chinese |
| Regulatory approvals |
CE, FCC, Class A, RoHS, CB, EAC, EMF, ETL, |
| Warranty |
5-year warranty |
|
|
| Weight |
|
| Product without stand (kg) |
TBD kg |
| Product with packaging (lb) |
TBD lb |
| Product without stand (lb) |
TBD lb |
| Product with packaging (kg) |
TBD kg |
|
|
| Dimensions |
|
| Set Height |
1158.74 mm |
| Wall Mount |
800 x 400 mm, M8 |
| Bezel width (L/R, T/B) |
16.7 mm(T/R/L), 39.42 mm(B) |
| Set Width |
1965.1 mm |
| Set Width (inch) |
77.37 inch |
| Set Depth |
116.227 mm |
| Set Depth (inch) |
4.58 inch |
| Set Height (inch) |
45.62 inch |
